SCHEMATIC DIAGRAM GAS - VERSION EUROPE
REF Designation
1 Regulator valve
2 Gas cylinder
3 Drain
4 Connection kit gas bottle
5 Rubber washers
6 Pictogram
7 Connection kit gas copper
8 PVC girdled sleeve
9 Gas appliance connection kit
Cooker
WARNING
Make sure the temperature of the stove before you close the hood.
