SCHEMATIC DIAGRAM GAS - VERSION US
Regularly check and replace the rubber tubings that link the cylinder to one end of the circuit
and the stove to the other one, depending on the norms and regulations in force in your country.
Pay particular attention to keep in good condition the screw thread of the cylinder on which the
regulator is. Check the condition of the regulator every year and change it if necessary. Use
regulators identical to the ones that are fitted.
Have the repairs carried out by someone skilled.
POSITION OF GAS BOTTLE
The locker for storing gas bottles can be reached through the cockpit.
The locker can accommodate a gas bottle. The locker is equipped with bottle fastening straps.
REF Designation
1 Regulator valve 12V
2 Gas cylinder
3 Drain
4 Stuffing box
5 PVC girdled sleeve
6 Electromagnetic valve for gas 12V
7 Pipe Propane Plastic
6
7
4
5
3
2
1
