ELECTRIC WINDLASS - BREAKER - FUSE
.
Operation relay - Location:
Engine compartment
1. Bow roller
2. Chain locker
3. Windlass 12V 1000W
4. Opening - Chain locker
5. Handle position
6. Chain rim 10mm
7. Clinch
ELECTRICAL BATTERY SWITCHES 12V
Control - Cupboard Saloon
WINDLASS CIRCUIT BREAKER
Location: Engine compartment
Windlass control -
Inside wheelhouse
Windlass control -
Wheelhouse Flying bridge
Location: Engine compartment
1. Positive - Port engine
2. Positive - Service
3. Positive - Power
4. Positive - Starboard engine
5. Negative terminal - Common
To Next Page
