POSITION OF FUEL SUPPLY VALVES AND
SEA WATER INLET VALVE FOR ENGINE
1. Sea water inlet valve for engine
2. Supply valve Fuel + Joining generator - Port tank
3. Supply valve Fuel + Joining - Heating - Starboard tank
Diesel oil tanks capacity: 2 x 450 litre.
Sea water inlet valve for engine (Reference 1)
View interior View Outside
Fuel supply valve (Reference 2 and 3)
