12
2 3 4 51 7
1 1
6
8 9
10
11
12
13
14
1 - Screen/ repeater for the electronic system
(optional fi tting).
2 - Compass.
3 - Port engine rev counter.
4 - Rudder angle indicator.
5 - Starboard engine rev counter.
6 - Adjustable steering wheel.
7 - VHF radio (optional fi tting).
8 - Bow thruster control (optional fi tting).
9 - Trim tab control.
10 - Engine controls.
11 - Air conditioning control (optional fi tting).
12 - Deck searchlight control (optional fi tting).
13 - Release pull handle of engine extinguisher.
14 - 24 V switches (for more details about their
functionalities, see p.66).
WHEELHOUSE HELM
