LEGEND OF THE OPPOSITE PICTURE / 24 V - 230 V ELECTRICAL PANEL
1 - Starboard water tank gauge.
2 - Port water tank gauge.
3 - Ammeter.
4 - Ammeter selector.
5 - General ON/OFF cut out.
6 - Generator control (optional fi tting).
7 - 230 V generator - shore supply selector / on board equipment.
8 - Voltmeter.
9 - 230 V generator - shore supply selector / air conditioning (optional fi tting).
10 - On board positive cut out.
11 - General negative cut out.
12 - Starboard engine positive cut out.
13 - Port engine positive cut out.
14 - Bow thruster positive cut out (optional fi tting).
15 - Bow thruster negative cut out (optional fi tting).
16 - 24 V / 230 V inverter control.
17 - Control to start the air conditioning.
18 - Water heater ON / OFF switches.
19 - 230 V selectors ON / OFF switches.
