Summary for the 110 V - 230 V elements
24 V / 230 V - 700 Va or 2500 Va INVERTER
When they are not supplied by the shore power socket or the generator, the following appliances on the UTILITY busbar function automatically with the inverter if it is switched on
(switch in REMOTE position). The 24 V batteries provide the current which is converted to 230 V or 110 V (US version).
GENERATOR
Force 11 Kva 50 Hz
Force 13,5 Kva - 110 V 60 Hz
SHORE POWER SOCKETS
Shore power socket - High Load 230 V - 50 Hz 32 Amp simple shore power socket Connection of aft starboard shore power socket box
Shore power socket - Air conditioning 230 V - 50 Hz 63 Amp simple shore power socket Connection of aft starboard shore power socket box
ELECTRIC DISTRIBUTION
UPPER bus supplied by generator or shore power
LOWER bus supplied by generator or shore power
CHARGE
230 V / 24 V - 60 Amp charger Recharge of the service and engine bank by generator or shore power
230 V / 24 V - 40 Amp charger Bow thruster charger supplied by the generator or the shore
230 V ou 110 V charger With optional generator to recharge the generator 12 V battery
