Location of the engines
1 - Fuel shut off valve.
2 - Fuel tanks.
3 - Fuel tank deck fi llers.
4 - Bilge fan.
5 - Fuel fi lter.
6 - Engine water inlet valve.
7 - Sea water fi lter.
8 - Engine.
9 - Pod.
1
4
3
5
2
6
7
8
9
BATTERY COUPLING
CONTROL
POD
FUEL VALVES
PULL HANDLES
OF FUEL VALVES
