TECHNICAL INFORMATION
5 - 13
Diagnostic Code List and Description
MAIN
CODE
SUB
CODE
DESCRIPTION DO NOT
SHIFT
LIGHT
INHIBITED OPERATION
DESCRIPTION
12 12 Oil level, low No No upshift above a calibration
range
12 23 Oil level, high No No upshift above a calibration
range
13 12 ECU input voltage, low Yes DNS, SOL OFF (Hy-
draulic default)
13 13 ECU input voltage, medium low No None: Shift adaptive feature
will not function.
13 23 ECU input voltage, high Yes DNS, SOL OFF (Hy-
draulic default)
14 12 Oil level sensor, low No None
14 23 Oil level sensor, high No None
21 12 Throttle position sensor, low No Use Throttle default value
21 23 Throttle position sensor, high No Use Throttle default value
22 14 Engine speed sensor reasonableness
test
No Use default engine speed
22 15 Turbine speed sensor reasonableness
test
Yes DNS, Lock in current range
22 16 Output speed sensor reasonableness or
rapid decel test
Yes DNS, Lock in current range
23 12 Primary Shifter or RSI Link Fault No Hold in last valid direction
23 13 Primary Shifter Mode Function Fault No Mode change not permitted
23 14 Secondary Shifter or RSI Link Fault No Hold in last valid direction
23 15 Secondary Shifter Mode Function Fault No Mode change not permitted
24 12 Sump oil temperature, cold Yes DNS
24 23 Sump oil temperature, hot No No upshifts above a calibra-
tion range
25 00 Output speed reasonableness test, de-
tected at 0 speed, (L)
Yes DNS, Lock in current range
(L)
25 11 Output speed reasonableness test, de-
tected at 0 speed, (1st)
Yes DNS, Lock in current range
(1 st)
25 22 Output speed reasonableness test, de-
tected at 0 speed 2nd
Yes DNS, Lock in current range
(2nd)
25 33 Output speed reasonableness test, de-
tected at 0 speed, 3rd
Yes DNS, Lock in current range
(3rd)
25 44 Output speed reasonableness test, de- Yes DNS, Lock in current range
