B), and less than 0.05 VDC between the Equalizer' s GND terminal and the battery ground terminal
(Battery A negative terminal that is connected to chassis ground). In most installations, the Battery
Equalizer' s terminals are wired directly to the battery terminals to prevent voltage loss that could occur in
switch contacts, connections, and long wire runs. Since the equalizer can be operated in temperatures up
to 71º or 75º C, use wire rated at least 90º C. See Wire and Fuse Size Chart.
Wire and Fuse Size Chart
Max wire length, in feet, between Equalizer and battery to keep voltage drop under 0.1
volt. The chart assumes wire carries no other load and wire temperature is below 80º C.
60-60 60-80 60-100 2 x 60-100
65-60 65-80 65-100 2 X 65-100
Wire
Size
AWG
Ring Terminal
Molex or UL
recognized
equal
60-10 60-20 60-50
66-60 66-80 66-100 2 X 66-100
#14 191930072 3.2 XXX XXX XXX XXX XXX XXX
#12 191930134 5.0 2.5 XXX XXX XXX XXX XXX
#10 191930134 7.7 3.8 XXX XXX XXX XXX XXX
#8 191930157 12.8 6.4 2.6 2.1 XXX XXX XXX
#6 191930251 19.4 9.7 3.9 3.2 2.4 XXX XXX
#4 191930278 35.2 17.6 7.0 5.9 4.4 3.5 XXX
#2 191930309 51.9 26.0 10.4 8.7 6.5 5.2 2.6
#1 191930333 65.4 32.7 13.1 10.9 8.2 6.5 3.3
#1/0 191930333 82.9 41.4 16.6 13.8 10.4 8.3 4.1
#2/0 191930346 105.5 52.7 21.1 17.6 13.2 10.5 5.3
Fuse F1 20 amp 30 amp 80 amp 80 amp 100 amp 125 amp 250 amp
Fuse F2 10 amp 15 amp 35 amp 40 amp 50 amp 80 amp 150 amp
Crimp the ring terminals using
Molex
tool 192840002 (14ga), 192840001 (10 -12ga), 192840035 (2 - 8ga) (phone
813-521-2700) and
AC Terminal
tool model 0280 (6 ga and larger) (phone 614-868-9828).
___________________________________________________________________
Testing and Troubleshooting
All Vanner equalizers fall into one of three distinct families. The three families operate differently and
must be tested differently. The following three test procedures apply
only
to the equalizer family listed.
CAUTION
Servicing of electrical systems should only be performed by trained and qualified technical personnel.
Equipment Required
VoltMeter having 0.01 volt resolution. (Fluke Model 87 Multimeter recommended).
Clamp-on amp meter (Fluke Model 36 Clamp-on Meter recommended).
Vanner Repair Service
Vanner offers a quick turn around factory repair service for Family 1 and Family 2 models. (Family 3, 4
and 5 models are non-repairable.) Send the unit to the address below with a note instructing us to repair
it. Include your name, phone number, shipping address (not a P.O. Box Number), and your purchase
order number.
