PREVOST X3-45 COMMUTER User Manual

MI18-37
Page 13 / 14
Writer: <QF7720955 rev 7>
EL
SUPPLEMENT
HOW TO INSTALL A NEW “CLIP-ON” UNLOADER COIL
1.
Loosen the screw securing the connector
to the coil and then unplug the connector
(A
). Keep the screw and the connector
rubber gasket for later use.
2. Unscrew the aluminum cap and discard.
3.
Remove the plastic capture nut and
discard.
4. Remove the coil and discard
5. Keep the O-ring on the stem.
6. Install the new clip-on coil on the stem.
7. Slide the coil over the stem assembly with
the O-ring at the base of the stem.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
