10
THREE STAGE CHARGE CYCLE:
An Electronic Control Module (ECM) controls both the output voltage and current of the charger through three
separate charge states:
1. A high current, fast charge state: Battery charges at 3,500mA fast charge current rate until battery
voltage reaches peak voltage.
2. A topping charge state: Battery charges at peak constant voltage and current begins to fall until
current is less than 700mA.
3. A precision oat charge state:Thechargerchangestotheoatstateandholdsthebatteryvoltage
  atcontinuousoatvoltage.Thisallowsthechargertoremainconnectedtothebatteriesduring
periods of non-use, keeping the batteries in a state of full charge.
4. Charger cut-off: To comply with mandate of DOE this charger automatically cuts off after 20 hours
of continuous operation, and CHARGE STATUS LED turns off. It is designed with auto restart to
keep batteries charged.
SAFETY FEATURES:
1. Short-circuit Protection – protects the charger from short-circuit damage.
2. Overcurrent Protection – protects the charger from overcurrent demand.
3. Overvoltage Protection – protects the batteries from damage.
4. Battery Polarity Reversal – protects the charger and batteries against incorrectly installed batteries.
5. Low Battery Voltage – when the battery ls under14V, the charger will not engage.
SPECIFICATIONS:
FAULT CODES
INDICATION CHARGE/FAULT - Red LED FAULT
1 Off No batteries - Voltage < 9V
2 Continuousashing 12 hour charge timed out
3 1ashevery3seconds Battery voltage < 14V
4 2ashesevery3seconds Batteries are connected in reverse polarity
5 3ashesevery3seconds Overvoltage from batteries
6 4ashesevery3seconds Overcurrent from charger
1 Input Voltage 100 – 240Vac +/-10%
2 Input Frequency 50–60 Hz
3
Output Voltage
Fast Charge (Bulk)
Float
AGM
DC 29.6V +/- 0.2V
DC 27.4V +/- 0.4V
GEL
DC 28.6V +/- 0.2V
DC 26.6V +/- 0.4V
4
Output Current
Fast Charge (Bulk)
DC 3,500mA
5 Battery Capacity 12-35 Ah (Suggested)
6 Operating Temperature -13˚F/-25˚Cto+122˚F/50˚C
7 Storage Temperature -13˚F/-25˚Cto+140˚F/60˚C
8 Power Supply Cord SJT,18AWGX3C,300V,105˚C
