14
THREE STAGE CHARGE CYCLE:
An Electronic Control Module (ECM) controls both the output voltage and current of the charger through three
separate charge states:
1. A high current, fast charge state: Battery charges at 5,000mA fast charge current rate until battery
voltage reaches peak voltage.
2. A topping charge state: Battery charges at peak constant voltage and current begins to fall until
current is less than 1A.
3. A precision oat charge state:Thechargerchangestotheoatstateandholdsthebatteryvoltage
  atcontinuousoatvoltage.Thisallowsthechargertoremainconnectedtothebatteriesduring
periods of non-use, keeping the batteries in a state of full charge.
4. Charger cut-off: To comply with mandate of DOE this charger automatically cuts off after 20 hours
of continuous operation. It Is designed with auto restart to keep batteries charged.
SAFETY FEATURES:
1. Short-circuit protection – protects the charger from short-circuit damage.
2. Overcurrent protection – protects the charger from overcurrent demand.
3. Overvoltage protection – protects the batteries from damage.
4. Battery polarity reversal – protects ‘the charger and batteries against incorrectly installed batteries.
5. Low battery voltage – when the battery ls under 14V, the charger will not engage.
NOTE: COMPLETE battery charge is NOT achieved until battery has charged 15 hours.
SPECIFICATIONS:
FAULT CODES
INDICATION CHARGE/FAULT - Red LED FAULT
1 LED is off. No batteries - Voltage < 9V
2 LED-continuousashing 12 hour charge timed out
3 LED-1ashevery3seconds Battery voltage < 14V
4 LED-2ashesevery3seconds Batteries are connected in reverse polarity
5 LED-3ashesevery3seconds Overvoltage from batteries
6 LED-4ashesevery3seconds Overcurrent from charger
1 Input Voltage 100 – 240Vac +/-10%
2 Input Frequency 50–60 Hz
3
Output Voltage
Fast Charge (Bulk)
Float
AGM
DC 29.6V +/- 0.2V
DC 27.3V +/- 0.4V
GEL
DC 28.6V +/- 0.2V
DC 26.6V +/- 0.4V
4
Output Current
Fast Charge (Bulk)
DC 5,000mA
5 Battery Capacity 18-50 Ah (Suggested)
6 Operating Temperature +32˚F/0˚Cto+104˚F40˚C
7 Storage Temperature -4˚F/-20˚Cto+140˚F/60˚C
8 Power Supply Cord SJT,18AWGX3C,300V,105˚C
