INTRODUCTION
The Battery Maximizer A24030-9C 24 volt battery charger is a fully automatic, multi-
stage full switching charger. It is designed to properly charge VRLA / SLA / AGM /
Gel lead-acid batteries without having to worry about overcharging. It may be used
in all parts of the world with its advanced universal AC input (110 or 220VAC). The
dual LEDs let you know the condition of the battery and if there are problems.
INSTRUCTIONS:
LED Function
CAUTION: If the charge LED remains red for more than 24 hours, unplug charger
from AC power and check the batteries. There may be a problem with the batteries.
Call for service if needed.
CHARGING: Before use, read all instructions and cautionary
markings on charger, battery and mobility aid.
Tum off all accessories on mobility aid device.
Placechargerinasafeandcleanenvironmentonahardsurface(oorordesktop).
Plug connector to appropriate port on the mobility aid.
Plug the charger into AC power.
The charger will begin charging automatically. If the Green Power LED does not illuminate,
check the connections. Note: If the battery voltage is less than 5VDC, then the charger
will not charge. The batteries may not be connected correctly or have been overdischarged.
LED CONDITION
Power • (green)
Charge • (red)
AC connection
Batteries fast charging
Power • (green)
Charge • (green)
AC connection
Battery fully charged
Power • (red)
Charge • (off)
Error; short circuit, leads reversed,
battery disconnected or battery
voltage less than 5VDC
