GENERAL INFORMATION
ACl245000 battery charger ls-an automatic, three-stage battery charger. It is designed to properly charge
VALA/ SLA /AGM /Gel Cell lead-acid batteries. With optimized algorithm that ensures the batteries receive
optimum charging from the delivery of an accurate three-stage charge cycle, ACl245000 charger provides a
lasting, safe and complete charge, without risk of over-charging and battery damage. It can be used in all
parts of the world with its universal AC power input design (100-240 VAC). The dual LED indicators display
updates to the user in real time, for the charging status and battery condition.
OPERATING INSTRUCTIONS
LED INDICATORS
CHARGING
• Before use, read all instructions and cautionary markings on charger, battery and any mobility aid device.
• Tum off all accessories on mobility aid device.
• Makesuretoplacethechargerinasafeandcleanenvironmentonadry,nonammablesurface.
• Connect the charger DC output plug to the port on the mobility aid device. Connect the charger AC plug
to an electrical outlet.
• The charger will start to charge the battery automatically. If the power LED does not illuminate, please
check the connections.
• To disconnect, reverse the procedures.
CHARGING
For 24V battery, if the battery voltage Is less than 10 VDC, the charger will not charge.
CAUTION: If the charge LED remains RED for more than 24 hours, unplug the charger from AC power
and check the batteries, there may be a problem with the batteries, call for service if needed.
LED Charge Status
Power Charge
Red
Red
AC poor connected
Battery fast charging
Power Charge
Flash Red
Green
AC power connected
Reverse polarity connection
Power Charge
Red
Green
AC power connected
Battery fully charged
