6
Note: Charger comes with one power cord depending on the charger model number. Please refer to the
table above for corresponding cord information.
AC CORD AND PLUG REQUIREMENTS
Cord rating: 120V, 1A, Type SJT, No. 18AWG (for use with 100-240VAC) 240V. 1A, Type SJT
or equivalent, No. 18 AWG (for use with 200 - 240V AC)
Plug rating: Type NEMA5-15P (for use with 100-120VAC) Always use a plug that matches the type and
rating of the AC outlet. Attachment plug with grounding pin (for use with 200 -240V AC)
Cord length: Min. 1.8m (6 feet). Max. 6.1 m (20 feet) including output cord.
Type: MustcomplywithrequirementssetoutbytheSafetyApproval/CerticationOrganization
of each country of use.
Note: Always use a plug that matches the type and rating of the AC outlet.
Model # Plug Type Input Voltage Power Cord
24BC2000T-1 UL AC 120V, 60Hz
24BC2000T-2 GS AC 230V, 50Hz
24BC2000T-3 SAA AC240V, 50Hz
24BC2000T-4 BS AC 230V, 50Hz
SPECIFICATIONS
POWER CORD SELECTION
1. Input Voltage 100 – 240Vac +/-10%
2. Input Frequency 50 – 60 Hz
3. Output Voltage
Fast Charge DC 29.6V
Float Charge DC 27.6V
4. Output Current
Fast Charge DC 2,000mA
Float Charge DC 500mA
5. Battery Capacity 7 – 18 AH (Suggested)
