30
SpecicationofLi-ionCharger
(Model NL07C-25HT)
DESCRIPTION:
NL07C-25HT is a smart charger specially designed for Li-ion battery pack composed cells in series.
ELECTRICAL SPECIFICATIONS:
1. Input: I00-240VAC, 50/60 Hz. Output: 29.05V± 0.2V 2.5Adc ± 10%
2. Charger output: The charger is preset by factory for charging 7 cells Li-ion battery pack.
Its charging mode:
(1) Constant current (CC) mode : at beginning of charging, an 2.5Adc±10% (1(ave))
constant charging current to charge the pack until the pack voltage reaches to
29.05V± 0.2V.
(2) Constant Voltage (CV) mode : the output will keep 29.05V±0.2V constant through
the end of charging.
(3) Pre-charge state: When battery voltage is lower than 21V±1V. will start the
  pre-chargerst.Thechargecurrentis30%ofCCchargecurrent:0.75Adc±10%.
3. The indicator signal chart:
LED 1 LED 2 Condition / Indicators
OFF ON
Power ON (power ON by plugging in AC source and without battery)
Flashing three times then ON
ON OFF Constant current mode
ON OFF Constant voltage mode
ON ON
Batteryfullycharged(terminatecurrent≤300
± 100 mA)
Slow Flash OFF Pre-charge mode
Red and green LEDs
ashsynchronously
Pre-charge mode fail
Red and green LEDs quickly
ashalternately
Overvoltage • Overcurrent • CC • CV mode current fail
