Specication of Li-ion Charger
(MODEL:LS-018C20-2402500)
DESCRIPTION:
LS–018C20-2402500 is a smart charger specially designed for Li-ion battery pack composed of cells in the series.
ELECTRICAL SPECIFICATIONS:
1. Input: 100–240VAC, 50/60 Hz Output; 29.4V ± 0.2V 2.5Adc±10%
2. Charger output: The charger is preset by the factory for charging 7 cells in this Li-ion battery pack.
Charging mode:
(1) Constant current (CC) mode: at beginning of charging, an 2.5Adc±10% (l(ave))
constant charging current to charge the pack until the pack voltage reaches to
29.4V±0.2V
(2) Constant Voltage (CV) mode: the output will keep 29.4Y±0.2V constant through
the end or charging.
(3) Pre-charge state: When battery voltage is lower than 21V±1V, will start the
   pre-chargerst.Thecharge-currentIs20%ofCCchargecurrent:0.5Adc±10%.
(4) Re-charge static: When fully-charged battery voltage drops lower than 28.3V±0.5V,
the charger will start a new charge cycle.
3. The indicator signal chart:
ATTENTION!!
Never use this charger to charge a non-rechargeable battery.
Signal / Indicator POWER (bi-color LED) STATUS (dual color LED)
• Stand by
• End of charge
Constant RED Constant GREEN
• Pre-charge state
• Charge state
ON Constant RED
• Overcurrent
• Overvoltage
• Over temperature
ON
Flash between RED and
GREEN every second
• Zero voltage pre-charge state
• Short circuit
ON
Flash between RED and GREEN
RED: 16ms; GREEN: 496ms
