IV. YOUR JET 2
SEATBACK
ARMRESTS
CONTROLLER
BODY SHROUD
Figure 3. The Jet 2
FOOTREST
DRIVE WHEEL
ANTI-TIP WHEELS
REAR CASTER WHEEL
SEAT
ASSEMBLY
POWER BASE
ASSEMBLY
Your Jet 2 has two main assemblies: the seat and the power base. See figures 3 and 4. Typically, the seating
assembly includes the armrests, seatback, and a joystick/controller. Your Jet 2 seat may also have some
optional accessories attached to it, such as a basket, a cane/crutch holder, or a cup holder. See XI. Options and
Accessories.
The power base assembly is the heart of your Jet 2. The power base assembly includes two drive wheels, two anti-
tip wheels, two rear caster wheels, a body shroud, and footrest.
JOYSTICK
MANUAL FREEWHEEL
LEVERS
