Jet 2/Rev F/Feb03 www.pridemobility.com 21
SLIDE JOYSTICK
MOUNTING ARM
INTO BRACKET
SETSCREW
Figure 11. Joystick And Bracket
V. ASSEMBLY
Figure 10. 9-pin Controller Connector
