Jazzy Air www.pridemobility.com 17
IV. COMFORT ADJUSTMENTS
To install the positioning belt:
1. Remove the rearmost screw that holds the seat hinge to the seat base on both the left and right seat hinges.
2. Insert the screw through the supplied washer, through the positioning belt, and into the seat base for each side
of the power chair seat.
3. Tighten both screws.
To adjust the positioning belt for operator comfort:
1. Once seated, insert the metal tab on one side of the belt into the plastic housing on the opposite side until you
hear a click. See fi gure 12.
2. Pull the excess strap attached to the metal tab until it is secure, but not so tight as to cause discomfort.
To release the positioning belt:
1. Press the push button mechanism on the plastic housing.
MANDATORY! Make sure the positioning belt is properly secured to the power chair and is
adjusted for operator comfort before each use.
MANDATORY! Inspect the positioning belt for loose parts or damage, including tears, worn spots,
bent hardware, damaged latch mechanisms, dirt or debris, before each use of the power chair.
If you discover a problem, contact your authorized Pride Provider for maintenance and repair.
