Pride Luna Victory - Battery Connection and Scooter Label

Luna Victory Series www.pridemobility.com 9
II. SAFETY
Indicates tie-down points on the scooter.
Scooter information label.
60 AMP
CIRCUIT BREAKER
BATTERY BATTERY
125A/50V
Battery Set Configureation:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Post.
Connect Black wire to Black Negative (-) Terminal Posts.
Keep area dry.
Manufactured in
Keep area clean.
