Quantum 610 Series www.pridemobility.com 29
Figure 24. Battery Installation
REAR SHROUD FASTENERS
REAR SHROUD
FRONT BATTERY
REAR BATTERY
VII. CARE AND MAINTENANCE
Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts.
Connect Black wires to Black Negative (–) Terminal Posts.
BATTERY WIRING DIAGRAM LABEL
