III. YOUR POWER CHAIR
THE QUANTUM 610
The Quantum 610 has two main assemblies: the seat assembly and the power base assembly. See figure 1. Typi-
cally, the seat assembly includes the armrests, seatback, and seat base. The power base assembly includes two
motor/brake assemblies, two drive wheels, four caster wheels, two batteries, and wiring harnesses. See figure 1,
2, and 3.
SEATBACK
REAR
SHROUD
DRIVE WHEEL
CASTER WHEEL
Figure 1. The Quantum 610 Series
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
FRONT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
ARMRESTS
CONTROLLER
CASTER WHEEL
