III. YOUR POWER CHAIR
THE VOGUE
Your power chair has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake
assemblies, two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and wiring harnesses.
POWER
BASE
ASSEMBLY
SEAT
ASSEMBLY
ARMREST
CONTROLLER (VR2 SHOWN)
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Vogue
JOYSTICK
FRONT RIGGINGS
SEAT BASE
To Next Page
