1 - Assembly Drawing
1
2
3
4
5
7
6
1. Control Box
2. Control Panel
3. Pressure Adjustment Knob
4. Operating Handle
5. Stabilising Feet
6. Heat Pattern (21cm x 29.5cm)
7. Lower Platen (Unheated)
When the press is removed from the box the Stabilising feet (5)
may be disassembled for shipping. Please screw the feet into the
threaded holes on the legs of the press before operang the press.
ATTENTION!
