Installation of aesthetic panel
【 】Figure4a
2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of
dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by
screws and bolts(See figure 4b) .
Installation of aesthetic
wooden panel
【 】Figure4b
1
2
. take away the four
short screws
. pin up the four long
screws
19
