Prima PRLD375 - Door Preparation and Drilling

BUILT-IN INSTALLATION
Position Paper
Make the mark on the door
1
Position Paper Position Paper
Top Top
Lef t Open
Rig ht Open
Fixed position paper on the door.
2
16- 22mm
12m m
35m m
12mm
2mm
Drill hole on the door
3
10
30
