5.05"
(124.0mm)
5.68"
(144.3mm)
1.00"
(25.40mm)
Verify Scale
Before Using
Template
1.00"
(25.40mm)
R16/R165
Mounting
Holes
R16/R165 Hole Cutout
Installation
illus.-3.3
