Prime R142 - Page 13

13
6.48"
(164.5mm)
4.78"
(121.5mm)
1.00"
(25.40mm)
Verify Scale
Before Using
Template
1.00"
(25.40mm)
R1693/R1694
Mounting
Holes
6.02" x 8.74"
(153.0mm x 222.0mm)
R1693/R1694 Hole Cutout
illus.-3.6
Installation
