Sorting your hardware ahead of time will speed up assembly time. Sort all your
hardware now so it will be ready before you start assembly.
NOTE:
A. An electric screwdriver is helpful in assembly. However, please set to low torque and
use caution because you could over-tighten the hardware and strip the screws.
B. Indentation mounting guides are small so look closely when attaching hardware.
C. Table top can be set on top of two saw horses. Although this will make assembly easier
it is not necessary to complete assembly. Always use shipping container to protect the painted
surface of the table top.
CAUTION: Make sure that the table top is secure on sawhorses and NEVER leave
the table top unattended.
ASSEMBLY TIPS
2
(Qty. 6)
1/4-20 Zinc
Locknut
(Qty. 24)
(Qty. 2)
(Qty. 4)
(Qty. 2)
(Qty. 4)
(Qty. 4)
(Qty. 6)
(Qty. 100)
(Qty. 16)
(Qty. 4)
(Qty. 4)
S.M.S. (Qty. 4)
#8 x 1 7/16
Sheet Metal Screw
(Qty. 12)
1/4-20 x 3 1/4 Hex Head Bolt
37
38
1/4-20 x 2 1/4 Hex Head Bolt
(Qty. 4)
#10-24 X 1/2 Phillips
Pan Head Screw
(Qty. 4)
1/4-20 x 2 1/2 Hex Head Bolt
(Qty. 2)
39
Not UsedNot Used
