THERMOSIPHONIC SOLAR WATER HEATERS / TECHNICAL DOCUMENTATION / JANUARY 2021 PAGE
32
TABLE 5
CHECKLIST BEFORE START - UP
NUMBER
ACTION YES
NO
1
system facing South for the North hemisphere
and North for the South hemisphere?
2
Did you check that the thermosiphonic system is not located in the
shadow throughout the whole year?
3
Was the collector installed with an
installation angle between 15
º
45º?
4
Is the thermosiphonic system installed at least 1m distance from the
walls or the end of the roof?
5 Did you use the provided manual during installation?
6 Is max operational pressure 10bar?
7
If the pressure of the cold water is more than 10bar, did you install a
pressure reducer?
8 Did you notice the statics?
9
Did you get required measures to prevent water penetration? Did
you seal accordingly?
10
according to local weather conditions to
avoid freezing and UV damage?
11 Did you connect all the fittings?
12 Are all hydraulic connections free of heavy loads?
13 Did you check for leakages?
14 Did you use the original glycol for freezing protection?
15 Did you check that all valves are working properly?
16 Did you check the mounting system for visible damage?
17 Did an authorized electrician install the original electrical heater?
18 Did you install the system according to manual?
19 Are all connections done correctly (screws are tighten, etc.)
20 Is the tank fastening done correctly?
21 Did you do the starting up of the system according to manual?
22 Did you do a functional check 30 minutes after installation?
