THERMOSIPHONIC SOLAR WATER HEATERS / TECHNICAL DOCUMENTATION / JANUARY 2021 PAGE 6
Model 160/2 160/2.5 200/2.5 200/ 4 300/ 4 300/ 5
Dimensions
[45 degree
inclination]
Width
(mm)
Α
1314 1314 1680 2594 2594 2594
Length
(mm)
Β
1624 1903 1903 1624 1624 1903
Height
(mm)
C
1731 2010 2010 1731 1731 2010
System weight empty (kg) 87.15 93.4 108.4 131.3 154.3 166.8
System weight full (kg) 239.5 245.9
299.9
324.1 433.1 445.9
Optional electrical
resistance (kW)
3,5 3,5 3,5 3,5 3,5 3,5
Tanks
Tank volume
(l)
151 151 190 190 276 276
Tank weight
empty (kg)
58 58 73 73 96 96
Tank weight
full (kg)
209 209 263 263 372 372
Length (mm) 1230 1230 1520 1520 1980 1980
Diameter
(mm)
Ø 500
Collectors
Dimensions
of collector
(mm)
1235x1625
x85
1235x2020
x85
1235x2020
x85
1235x1625x
85
1235x1625x
85
1235x2020
x85
Number of
collectors
1 1 1 2 2 2
Gross area
per collector
(m²)
2.00 2.50 2.50 2.00 2.00 2.50
Weight per
collector
empty (kg)
29.15 35.4 35.4 29.15 29.15 35.4
Max.
working
temp.
180ºC
Thermal
liquid per
absorber (l)
1.38 1.55 1.55 1.38 1.38 1.55
Max.
collector
circuit
working
pressure
2bar
