11
PR7310
∆ Not Shown.
* Standard hardware item available locally.
† Not available as a repair part.
REPLACEMENT PARTS LIST FOR 10
”
BENCH GRINDER
Ref. Part
No. Description Number Qty.
1
1
⁄4-20 x
3
⁄4” Pan head screw * 10
2 #10-24 x
3
⁄8” Flange screw 03207.00 3
3 Spark guard (Set of 2) 25815.00 1
4 Wheel guard cover 16911.02 2
5 Flange 24480.00 2
6 1”-8 Hex nut (LH thread) 00111.00 1
7 Inner wheel flange 24481.00 2
8 Grinding wheel (36 coarse grit) 02040.00 1
9 Grinding wheel (60 med. grit) 02039.00 1
10 Capacitor 16895.00 1
11
3
⁄8-16 x
3
⁄4” Hex head bolt * 2
12
3
⁄8” Flat washer * 4
13 Bracket (left) 26290.00 1
14
5
⁄16-18 x 1” Knob 25812.00 2
15 Dust collector hose 08070.02 1
16 Tool rest (left) 25813.00 1
17
5
⁄16” Flat washer * 2
18 Tool rest (right) 25825.00 1
19 Wavy washer 16620.00 1
20
1
⁄4-20 x
3
⁄8” Knob 25816.00 2
21 Upper eyeshield bracket (left) 25177.00 1
22 Upper eyeshield bracket (right) 25188.00 1
23 Eyeshield kit 32290.00 1
24
3
⁄8-16 x
1
⁄2” Knob 25817.00 2
25 1”-8 Hex nut (RH thread) 00110.00 1
26 Wheel guard 26057.00 2
Ref. Part
No. Description Number Qty.
27
5
⁄16-18 x
5
⁄8” Hex head bolt * 6
28
1
⁄4-20 x 2” Flange screw 03209.00 8
29 Endshield 16913.02 2
30 Bearing 6206ZZ 00297.00 2
31 Motor fan 01639.00 1
32 Armature † 1
33 Stator with housing † 1
34 Grommet 16916.00 2
35 Line cord 00090.00 1
36 Strain relief 01601.00 1
37 Strain relief plate 08172.00 1
38 Base 16917.02 1
39 Switch with key 08066.01 1
40 Switch plate 08173.00 1
41
5
⁄16” Lock washer * 10
42
5
⁄16”-18 Hex nut * 4
43 Capacitor clamp 16918.00 1
44 Capacitor 08174.00 1
45 Capacitor cap 01638.00 2
46 #10-24 x
1
⁄4” Flange screw 03210.00 10
47 #10 Serrated washer * 1
48 Stationary switch 08175.00 1
49 Rotating switch 00299.00 1
50 Base cover 16919.00 1
51 Bracket (right) 26291.00 1
