REPLACEMENT PARTS LIST FOR 6
”
BENCH GRINDER
PR736
∆ Not Shown.
* Standard hardware item available locally.
† Not available as a repair part.
Ref. Part
No. Description Number Qty.
1 #10-24 x
1
⁄2” Pan head screw * 6
2 Spark guard (set of 2) 30014.00 1
3 Wheel guard cover 24462.02 2
4
1
⁄2”-12 Hex nut (LH thread) 00064.00 1
5 Flange 18904.00 2
6 Inner wheel flange 17315.00 2
7 Grinding wheel (36 coarse grit) 02034.00 1
8 Grinding wheel (60 med. grit) 02033.00 1
9
1
⁄4-20 x
3
⁄8” Flange screw 16670.00 6
10
3
⁄8-16 x
3
⁄4” Hex head bolt * 2
11
3
⁄8” Flat washer * 4
12 Bracket (left) 25810.00 1
13 Tool rest (left) 25813.00 1
14
5
⁄16” Flat washer * 2
15 Bracket (right) 25826.00 1
16 Tool rest (right) 25825.00 1
17 #10-24 x
3
⁄8” Pan head screw * 4
18 Upper eyeshield bracket (left) 25177.00 1
19 Upper eyeshield bracket (right) 25188.00 1
20 Eyeshield kit 32290.00 1
21
3
⁄8-16 x
1
⁄2” Knob 25817.00 2
22 Wheel guard 25986.00 2
Ref. Part
No. Description Number Qty.
23 5mm-0.8 Hex nut * 2
24
1
⁄4-20 x
1
⁄2” Knob 25816.00 2
25 Endshield 16617.02 2
26 Bearing 6202ZZ 01540.00 2
27 Motor fan 01608.00 1
28 Armature † 1
29 Stator with housing † 1
30 Grommet 01066.00 1
31 Line cord 00067.00 1
32 Strain relief 04055.00 1
33 #10-24 x 1/4” Flange screw 3210.00 6
34 Base 23757.02 1
35 Rocker switch with key 08066.01 1
36 Cover 23758.00 1
37
1
⁄4” Lock washer * 2
38
1
⁄4”-20 Hex nut * 2
39
5
⁄16-18 x 1” Knob 25812.00 2
40 Capacitor 16908.00 1
41 Bumper 23991.00 4
42 #10 Serrated washer * 3
43
1
⁄2”-12 Hex nut (RH thread) 00548.00 1
