REPLACEMENT PARTS LIST FOR 8
”
BENCH GRINDER
Ref. Part
No. Description No. Qty.
1 #10-24 x
7
⁄8” Pan head screw – 10
1 #10-24 x
1
⁄2” Pan head screw * 10
2 Wheel guard 26056.00 2
3 Spark guard (set of 2) 25815.00 1
4 Wheel guard cover 24496.02 2
5 Flange 24497.00 2
6
5
⁄8”-11 Hex nut (LH thread) 00088.00 1
7 Inner wheel flange 24498.00 2
8 Grinding wheel (36 coarse grit) 02038.00 1
9 Grinding wheel (60 med. grit) 02037.00 1
10
5
⁄16-18 x 1” Knob 25812.00 2
11
3
⁄8-16 x
3
⁄4” Hex head bolt * 2
12
3
⁄8” Flat washer * 4
13
5
⁄16” Flat washer * 2
14
1
⁄4-20 x
3
⁄8” Knob 25816.00 2
15 Dust collector hose 08070.00 1
16 Tool rest (left) 25813.00 1
17 Bracket (left) 31447.00 1
18 #10-24 x
3
⁄8” Flange screw 03207.00 1
19
3
⁄8-16 x
1
⁄2” Knob 25817.00 2
20
5
⁄8”-11 Hex nut (RH thread) 00087.00 1
21 Upper eyeshield bracket (left) 25177.00 1
22 Upper eyeshield bracket (right) 25788.00 1
23 Eyeshield kit 32290.00 1
24 Stationary switch 25171.00 1
25 Tool rest (right) 25825.00 1
Ref. Part
No. Description No. Qty.
26 5-0.8 mm Hex nut * 4
27
1
⁄4-20 x
1
⁄2” Hex head bolt * 6
28 5-0.8 x 228mm Flange screw 16654.00 4
29 Endshield 16627.02 2
30 Bearing 6204ZZ 00989.00 2
31 Motor fan 22041.00 1
32 Armature † 1
33 Stator with housing † 1
34 Grommet 01066.00 1
35 Line cord 00090.00 1
36 Strain relief 04055.00 1
37 #10-24 x
1
⁄4” Flange screw – 7
37 #10-24 x
1
⁄4” Flange screw 03210.00 9
38 Base 24499.02 1
39 Switch with key 08066.01 1
40 Base cover 24500.00 1
41
1
⁄4” Lock washer * 8
42
1
⁄4”-20 Hex nut * 2
43 Capacitor clamp 16655.00 1
44 Capacitor 16646.00 1
45 #10 Serrated washer * 5
46 Base bumper 23991.00 4
47 Wavy washer 16640.00 2
48 Bracket (right) 31448.00 1
49 Centrifugal switch 25172.00 1
∆ Operators manual 36626.00 1
