11 EN | ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
1. Wear safety glasses, Don’t cram wood into outfeed side.
2. Before use. check that all screws connections are properly
tightened.
3. Do not force the tool. Let the feed mechanism do the work. Never
insert objects or body parts in the outfeed.
4. Check regularly that the rubber roller and iron roller are clean. If the
rollers are contaminated the workpiece will not infeed correctly- risk
of persona injury.
5. Do not machine workpieces with many knots or sprigs.
6. The operating position is in front of the machine. Stand by the side
of the infeed table.
7. Remove any nails,screws and other metal objects from the
workpiece before machining.
8. Check that the blades are correctly installed.
9. Handle the knife blades with care--risk of personal injury and/or
damage to property.
10. Never start to planer until the blade holder has reached full speed.
11. Never use blunt blades-risk of kickback.
12. Always replace or sharpen both blades at the same time. Both
blades must be of the same size and weight.
13. Never insert your fingers or other body parts in the chip outlet--risk
of personal injury-
DANGER.
14. Pls check the recoil claw is in the correct position.
15. If infeed wood not smooth,pls don’t force the wood,check if machine
have some problems.
OPERATION STEPS
Unpacking
Carefully unpack the machine. The packaging must be recycled in
accordance with local regulations.
WARNING!
Turn off the machine and unplug the power cord before cleaning performing
maintenance and adjustment.
Assembly
Before using the machine must be in accordance with the requirements of
the assembly complete.
Install depth Adjustment handle (Pic.2)*
Place the depth adjustment handle (F) on the protruding shaft to the right
of the machine’s top surface. Push on the handle firmly and lock it with
the supplied screw.
Adjust depth of the planer In order to be able to completely correct and safe
operate this machine, User must be know how to correct adjust.
VERY IMPORTENT! (PIC. 3)*
Rotate the depth adjustment handle(F) a circle, the machine depth can be
rised or lowered by 1.5 mm.
Before using, pls planer the wood a few times, that’s can be ensure the
surgace of the wood is completely horizontal in later use.
Please refer to the correct wood width range to adjust the depth of the
one-time planer:
At first, user needs a ruler to measure the thickness of the wood to be
planed, Then obervation depth label (H) to adjust the depth label to the
thickness of the planer required by the user.
Such as: the thickness of wood it’s 200mm, user wants to planer 2mm, so
depth label pointer is at 198mm, In this way, the thickness required by the
user can be reached during the one- time working process.
Pls note:The distance between the bottom of the machine and the knife
shaft is the thickness of the wood when it is planed; The difference
between the thickness of the wood when it comes out of the machine
and the thickness when it comes in is the thickness of the wood that was
shaved off.
WARNING!
It is forbidden to planer the thickness above 2.5mm at one-time.
The length of the wood must not be less than 153mm.The thickness of the
wood must not be less than 125mm.
Operate switch (power ON/OFF) (Pic. 4)*
Plug the power cord into the mains supply. If you are using an extension
cord, the cross section of the conductors must be sufficient for the tool’s
power supply. Avoid inappropriate use of cable. as this can lead to voltage
drop and cause power loss and over heating.
This planer is equipped with an electromagnetic switch.
Press the green button marked “I” to start the machine.
Press the red button marked “O” to stop the machine.
Overcurrent protective device correct use and replacement (I) (Pic. 5)*
When the load power is too large, the current exceeds the load, so the
overcurrent protective device will jump!
1. When the overcurrent protective device jump,first disconnect the
power supply of the machine, then press the protective button to
reset it
2. When press the protective button to reset it, don’t reboot
immediately. Need wait for the machine temperature to cool then
start for use.
3. If overcurrent protective device jump frequently. Pls replacement
a new.
ADJUST TABLE EXTENSION (J) (PIC. 6)*
Attention: this adjustment is already factory set ok ,in order to avoid to
effecting the function of the machine . need to check again.
1. Put the blade holder rise to a suitable height , so that it is easily
assembly.
2. Place a horizontal rule on the main worktable, use rule to measure
the table extension (J) and main worktable’s level.
3. If the table extension (J) are not flush with the main worktable,
loosen the nut (P) and turn the screw (Q) until table extension’s
rollers and the main worktable touch the ruler, Adjust both the left
and right -hand table extensions (J).
PARALLELISM ADJUSTING (PIC. 7)*
ATTENTION
This adjustment is already factory set ok. in order to avoid to effecting the
function of the machine. need to check again.
Poor parallelism is usually caused by misaligned blades. Always check that
the blade holder and the work table parallel before attempting to adjust the
parallelism setting.
1. Place the machine on its side and rotate the cross rod bearings
(S) fig.1 .
2. Move the conical gear wheel (T) towards the clamp until it runs
freely from the second gear wheel (fig.2).
3. Turn the second gear wheel to adjust the height of the blade holder
on the side where the gear wheels are located. One tooth shifting
anti-clockwise raises the blade holder 0.1mm (H).
Replacing and Adjusting the blades
WARNING!
Turn off the machine, unplug the power cord and wait until all moving parts
have stopped completely before replacing or adjusting the blades.
Dismantling the knife blade (Pic. 9)*
1. Use allen wrench (N) to remove the dust hood (V) by loosening the
screws (U), see below picture.
2. Use the double open wrench (N) to loosen the blade locking
plate (B) and knife blade (C) by turning the outer hexagon bolt
(A) clockwise. The knife blades are spring-loaded (D) and can be
remove when the blade locking plate is removed.
3. Remove the knife blade and blade locking plate.
Install the knife blade (Pic. 10)
1. Place the knife blade against the blade locking plate, in the correct
position relative to the pins.
2. Insert the knife blade and knife locking plate together in the slot and
lock in position by turning the outer hexagon blot (A) anticlockwise.
Ensure that the blades face in the right direction (see picture).
3. Set the height of the knife shaft of the knife blades as 1mm with
the bit gauge,That two support blocks on left and right side of bit
gauge are pressed against the knife blade.(Loosen, if necessary, the
clamping screws to move the blade to the correct position. ) When
the knife blade is positioned correctly. Hold it firmly in place and
To Next Page
