10
4.2.5 Frequency
Measuring range
Resolution
Accuracy
30Hz~1000 Hz
0. 1Hz
± (0.5% Reading + 2digits)
Current channel: Sensitivity 5mA, measurement range 30~1000Hz
Voltage channel: Sensitivity 0.5V measurement range 30~1000Hz
Input protection: Max.600V DC or AC valid value.
4.2.6 Temperature
Measuring range
Resolution
Accuracy
-20 ~1300
1
± (1% Reading + 3digits)
-4 ~2372
1
± (0.5% Reading + 2digits)
4.2.7 Transistor
Range
Description
Test Conditions
hFE
Display approximate
value of hFE,(0-1000)
Basic current is about 10μA VCE is
about 2.5V
4.2.8 Electric resistance
Measuring range
Resolution
Accuracy
6k
1
±(1% Reading +3 digits)
60k
10
600k
100
6M
1k
±(1.2% Reading +5 digits)
10M
10k
Input protection: Max.600V DC or AC valid value.
4.2.9 Capacitor
Measuring range
Resolution
Accuracy
60nF
0.01nF
± (4.0% Reading +5 digits)
600nF
0.1nF
6F
1nF
60F
10nF
600F
100nF
6mF
1uF
Input protection: F630mA/250V fuse or 600V/PTC .
Min. measurement capacitor: 1nF
4.2.10 Continuity test
Function
Description
Testing Environment
When the built-in beeper
sounds, the resistance being
tested is less than about 30.
Test current:: About 0.6mA;
Open circuit voltage: About
1.0V.
Input protection: Max.600V DC or AC valid value.
