When the measurement is completed, press the power key , to shut
down the instrument power supply.
Warning: In order to avoid safety accidents such as
potential electric shock or personal injury etc., please
comply with safety work norms:
3.6 AC/DC Current/ Frequency / Capacitor measurement
Press the key to start the power of the instrument.
Insert the red test lead into the mA socket, and the black test lead into
the COM socket.
During measuring the capacitor, parallel connect the test lead to both
ends of the capacitor to be measured; during measuring the current,
connect the test lead in series to the circuit to be measured. The
instrument will recognize and measure automatically.
Read measurement results from the display screen. When measuring
DC voltage, the current polarity of the testing ends of the red test lead
will show synchronously on the display.
When measuring AC current, press the key to display frequency,
and then press the key to shift back to AC current display.
When the measurement is completed, press the power key to shut
down the instrument power supply.
Max. current measurement of the instrument is 600mA, and
the min. current measurement is 5mA.
During measuring the maximum capacitor, it requires about
10 seconds to display the measurement result.
Warning: In order to avoid safety accidents such as
potential electric shock or personal injury etc., please
comply with safety work norms:
3.7 Temperature Measurement
Press the key to start the power of the instrument.
Take off the test lead and push down the Toggle switch on the
instrument panel lightly, till the Toggle switch is locked.
Insert the temperature probe of the K-type thermocouple into the socket
of the temperature probe of the temperature probe of the K-type
thermocouple.
Read measurement results from the display screen.
Press the key to shift between degrees Celsius and Fahrenheit.
When the measurement is completed, press the power key to shut
down the instrument power supply.
