2
Tes t
Functions
Range Accuracy Remarks
DC V 0-0.1-2.5-10-50-
250 V-1000V
 3% FSD.
 4% FSD.
For 1000V
Input Impendence:
20K/V Overload
Protection: Max.
1000V AC/DC
BUT 0.1V/2.5V/10V
250V Max.
Null DCV ±-5V, ±25V  5% FSD.
Input Impedance: 40K/V
Overload 1000V Max.
AC V 0-10-50-250V
-1000V
 4% FSD.
 5% FSD.
For 1000V
Input Impendence:
9K/V Overload
Protection: Max.
1000V AC/DC
But 10V/50V only
250V Max. Band
width: 40 ~10K Hz
DC mA 0-0.05-2.5-25-25
0 mA, 10A
 3% FSD.
 4% FSD.
For 10A
Drop Voltage: 250 mV
Overload protected by
Fuses 0.5A/250V &
10A / 250V at 10A
range, and Oxide
Varactor.<250V AC/
DC(5s). Max. test time
1min. for 10A.
 X 1: 0.2 ~ 2K
Midscale at 20
X 10: 2 ~ 20K
Midscale at
200
X 100: 20~
200K Midscale
at 2000
X1K: 200~ 2M
Midscale at 0K
X10K: 2K
~20M Midscale
at 200K
 4% of
ARC of
Scale
Length
Overload protected by
the Oxide Varactor &
Fuse <250V AC/DC
(5s).
