2 CARACTERISTIQUES
3 FEATURES
R6X Receiver (#70206)
Digital receiver with 6-channel able to effectively control model airplanes or gliders.
Power supply from 4,8 V to 8,4 V (2S LiPo).
Reverse polarity protection.
Very low Amp draw.
Very good resistance to voltage drops (insured up to 3.15 V operation).
Very low reboot delay in case of loss of power.
Receiving in the 2.4 GHz FHSS technology, providing a highly secure connection, optimum responsiveness, increased
range and the ability to fly more safely.
High sensitivity allowing a ground range of more than 500m (in flight range is way higher)
Very useful binding button, impossible to « loose » on the field.
30mm long antenna allowing very easy mounting in any model.
Very lightweight and small allowing this receiver to be mounted on any kind of models.
Failsafe servo position setting to place servo in a certain position after a loss of signal.
PARAMETRES VALEUR
Dimensions 34,2 x 18,4 x 8,7mm
Weight 6,5g
Receiving signal range 2,4GHz (2,4 à 2,483MHz)
Receiving signal type FHSS
Number of Channels (functions) 6 on UNI connectors
Power supply 4,8V to 8,4V on dedicated connector
Amp draw < 40mA
Security features Binding with Tx and programmable fail safe function
Channels resolution 1 µs
28
Battery connector
Channels connectors
Status LED
Binding button
Antenna
