45
47
Pin
2
Ø5x20
48
Leaf spring with button
1
49
Foldingmechanism handle
1
50
Self-locking nut
1
M8
51
Spring
1
52
Washer
2
M8
53
Socket head screw
1
M8x60
EXPLODED VIEW
