3
The modified sinusoidal curve produces an effective voltage (RMS) of 110 volts with
higher transformer/inverter power. Most AC voltmeters are calibrated to RMS voltage
and assume that the measured wave form is a pure sinus curve. Consequently these
instruments do not correctly read out the effective voltage of the modified sinusoidal
curve and, when measuring the transformer/inverter output power, the measurement
instrument measures about 20 to 30 volts too low. To exactly measure the output
voltage of the transformer/inverter, use a voltmeter that correctly measures
theRMSvoltage, such as a Fluke 87, Fluke 8060A, Beckman 4410, Triplett 4200 or a
similar multi-function instrument that detects the „true RMS“.
Note:
The original cable uses the transformer/inverters entire resources and maximises the
efficiency. The connection cable should not be longer than 10 meters. Otherwise, the
efficiency can be influenced.
Important:
Never operate the transformer/inverter with any power source other than a 12 volt
battery. Do not randomly replace the DC 12V cable. If the transformer/inverter is
connected to another power source, make sure that the transformer/inverter is not
located near flammable smoke or gasses. Make sure that the power consumption of
the unit to be operated is compatible with the transformer/inverters capacity. Only use
standard blade terminal fuses. If an audible alarm continues or an automatic
switch-off occurs, immediately switch the transformer/inverter to OFF. Do not
reconnect the transformer/inverter until the problem has been discovered and
repaired. To prevent the battery from discharging:
Make sure:
Type/Specification(W)
INV150
150 W
INV300
300 W
INV600
600 W
INV1000
1000 W
INV1500
1500 W
INV2000
2000 W
Max. output (W)/5 min.
300
600
1200
2000
3000
4000
Inv erter ef ficiency (%)
90±1
90±1
90±1
90±1
90±1
90±1
Input voltage (12V/DC)
11-15
11-15
11-15
11-15
11-15
11-15
No-load current (A)
<0.20
<0.35
<0.65
<1.10
<1.10
<1.10
Euro output power (V/AC)
230
230
230
230
230
230
Weight (kg)
0.75
0.85
1.40
1.90
1.90
1.90
Overheating protection (°C)
85±5
85±5
85±5
85±5
85±5
85±5
N. Ambient temperature (°C)
-20 – 40
-20 – 40
-20 – 40
-20 –40
-20 –40
-20 –40
Overload protection
Yes
Yes
Yes
Yes
Yes
Yes
Short-circuit protection
Yes
Yes
Yes
Yes
Yes
Yes
