Pro MISSILE EVO - Page 2

2
I
A Basebar - 1x
B Extension - 2x
C Armrest - 2x
D 1mm spacer - 2x
E Extension adapter - 4x
F 5mm spacer - 6x
G Basebar adapter - 2x
H Basebar bolt - 4x
I Armrest bolt - 2x
J Thread part - 4x
K Stem - 1x (oponal)
L Endcap - 1x
bottom view stem
Brake out
Shift out
Brake in
Shift in
(from basebar)
Stem
Brake out
Shift out
Shift (extension) in
from extension/spacer
Brake in
Shift (basebar) in
A
B
C
D E
F
G
H
J
K
L
A
K
Basebar
