Soundchief CV5 Sound Cart Setup
Insert the two inserts at the bottom section of
the Soundchief CV5, as shown in the image.
4 x Mounngs
Assembling of wheels
2 x Wheels
10 x Inserts
Nut Bolt
3 x T-Type Allen Keys
(Size: 3mm, 4mm, 5mm)
Insert the wheel (Size:3”) and properly match
the inserts with the threads of the wheel and
then insert the bolt.
1 x L-Type Allen Key
(Size: 3mm)
2 x Rod Supports
Properly tighten the bolt using the 4mm Allen
key. Repeat the same process to insert all the
bolts.
