PROCRAFT SPI 320 - Page 17

EN | ENGLISH
17
Duty cycle at
maximum
current (%)
30% при
40℃
30% при
40℃
30% при
40℃
Power
consumption
(kW)
5,3
6,5
7,1
Welding wire
diameter
(mm)
Φ0.6-1.0
Φ0.6-1.0
Φ0.6-1.2
Welding
electrode
diameter
(mm)
Φ1.6-4.0
Φ2.0-5.0
Φ2.0-5.0
Protection
class
IP21S
IP21S
IP21S
Efficiency
(%)
85
85
85
Roller
diameter,
mm
200
200
200
Feed speed,
m / min
2,5-12
2,5-12
2,5-12
Welding
torch cable
length, m
3
Electrode
holder
(max.current
, cable
length)
200 A, 2.8 м
Earth cable
(max.current
, cable
length)
300 A, 2.2 м
Used welding
wire
5 кг 0.8 мм
Weight, kg
14
14,5
15
Model
CONSTRUCTION MIG MAG WELDING TORCH
1. Gas nozzles:
2. Monday key
3. Curent nozzles
Put together:
• No. 4 together put in No. 2
• No. 1 together
BEFORE IMPLEMENTING
Machine cooling
In order to achieve an optimum duty cycle of the power
parts, please pay attention to
the following conditions:
• Ensure adequate ventilation in the workplace
• Air inlet and outlet openings of the appliance
• Metal parts, dust or other foreign objects must not
penetrate the device
Ensure that the air supply to the machine is not covered
or blocked, otherwise the
cooling system may fail.
ATTENTION
Damage caused by foreign components!
The manufacturing guarantee expires in case of
equipment damage caused by
external components!
• Only use systems components and options
(current sources, welding torches, electrode
holders, remote control, spare and wear parts, etc.)
from our product range!
• Connect the accessory component to the
connection socket only when the power source is
switched off and lock it!
ATTENTION
Damage to equipment by operation in non-upright
position!
The devices are designed for operation in an upright
position. Operation in other
positions can damage or override the device and safety
devices of the device!
Risk of death!
The device may only be installed and operated on a
suitable, load-bearing and
level surface (also outdoors in accordance with IP 21)!
• Provide for non-slip, level ground and adequate
workplace lighting.
• Safe operation of the device must be ensured at all
times.
ATTENTION
Damage to equipment due to pollution!
Excessively high quantity of dust or other substances can
damage the device.
IMPLEMENTING
DANGER
Risk of injury from electrical voltage!
Contact of live parts, for example welding current
sockets, can be hazardous to
life!
• Commissioning only by persons with appropriate
knowledge of the use of arc welding devices!
• Connect the connecting or welding lines (for
example electrode holder, welding torch,
workpiece cable, interfaces) with the device
switched off!
Risk of injury from electrical voltage after switching off!
Working on the open
