6.
Finishing the
Installation
1. Swing the motor assembly up into position
under the mounting bracket. Secure the
bracket to the plate with the screws provided.
(Fig. 7)
2. Carefully lift the motor housing onto the
mounting plate, properly align the holes
and tighten the motor housing with the four
screws supplied.(Fig. 8)
Figure 7
Figure 8
Mounting
plate
Screws
Motor
Mounting
plate
Screws
Motor
housing
