TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
PACKAGE CONTENTS
Package Contents..................................................................................................................................
Parts Description....................................................................................................................................
Safety Information..................................................................................................................................
Operating Instructions............................................................................................................................
Care and Maintenance ..........................................................................................................................
Troubleshooting......................................................................................................................................
Warranty.................................................................................................................................................
Replacement Parts List..........................................................................................................................
3
4
5
7
9
10
12
13
Model No.
Pump
Motor
Voltage/Amps/Hz
Air Tank Capacity
Cut-in Pressure
Cut-out Pressure
CFM @ 40 PSI
CFM @ 90 PSI
Power Cord
NOTE: Avoid use of extension cords. If use of
an extension cord cannot be avoided, the cord
should be a minimum wire size of 14 AWG and
no longer than 30 feet. Use only a 3-wire
extension cord that has a 3-blade grounding
plug and a 3-slot receptacle that will accept the
plug on the product.
0210342
Oil free
1/3 HP
120/3/60
3 gallon
80 PSI
110 PSI
0.9
0.6
SJT 18AWG×3C / 72 in. length
SPECIFICATIONS
Air Tank
Tank Pressure Gauge
Air Pressure Regulator
Regulated Pressure Gauge
Quick Coupler
Drain Valve
A
B
C
D
E
F
G
1
1
1
1
1
1
1
DESCRIPTIONPART QUANTITY
Pressure Relief Valve
ON/OFF Switch
Power Cord
Handle
H
I
J
K
1
1
1
1
DESCRIPTIONPART QUANTITY
K
A
H
I
F
G
C
B
D
E
J
Electric Motor &
Air Compressor Pump
