4 ActivPanel Wall Mount Quick Install Guide
2
ii
i
A
D
E
F
C
B
ii
Model Highest vertical blade position
APT2-55, APT2-84
O
APT2-65, APT2-70
O
AP3-55, AP3-84
O
AP3-65, AP3-70
O
AP4-55 C
AP4-84-4K F
AP4-65 C
AP4-70 D
AP4-75, AP4-75-4k A
AP4-75-02, AP4-75-4k-02 C
AP4-80 A
AP5-70, AP6-70 A
AP5-75, AP5-75-4k, AP6-75-4K C
AP5-86-4k, AP6-86-4K C
VTP-65 C
