4
65” 75" 86"
A 1536.0mm (60.5") 1767.0mm (69.6") 2018.0mm (79.4")
B 960.0mm (37.8") 1093.0mm (43") 1236.0mm (48.7")
C 151.0-289.0mm (5.9-11.4") 228.0-365.0mm (9.0-14.4") 292.0-430.0mm (11.5-16.9")
D 600.0mm (23.6") 600.0mm (23.6") 700.0mm (27.6")
E 134.0mm (5.3") 146.0mm (5.7") 155.0mm (6.1")
ActivPanel Nickel Quick Install Guide 7
